Basic Info.
| Plate shear (A stroke can cut flat steel thickness×width) | 20×300 mm | The maximum size can be cut steel | 10×480 mm |
| Bar diameter – Bar diameter | 50 mm | Square steel side length – Square steel side length | 50 mm |
| Channel diameter – Channel diameter | 16 | I-steel model – I-steel model | 16 |
| Equilateral angle of 90℃, shear – Equilateral angle of 90℃, shear | 140×12 mm | Die cut – Thickness | 13 mm |
| Die cut – Width | 57 mm | Die cut – Depth | 100 mm |
| Die cut – Thickness | 20 mm | Die cut – The maximum diameter | 30 mm |
| Punching | 90 T | Deep Throat – Deep Throat | 355 mm |
| Maximum stroke – Maximum stroke | 80 mm | Electric motor – Model | Y132M2 – 6B35 |
| Electric motor – Power | 7.5 kW | Electric motor – Speed | 960 r/min |
| Condition | Used | Brand | JINSANLI |
| Date of Manufacture | 202 | Country of Origin | China |
