Used Drilling Rig XSL3-160 for sale

Used Drilling Rig Product Description

modelXSL3-160
Winch lifting force1.5T
Quickly increase speed32m/min
Quick lowering speed60m/min
Maximum speed95/190r/min
Drilling diameter125-330mm
drill depth300-450m
Speed2.4km/h
Walking modeundercarriage

1. Equipped with Yuchai Stage III engine. Electronic fuel injection reduces fuel consumption and is more environmentally friendly. The electronic control technology effectively reduces stalling, reversing, and smoke emission issues. It can automatically display engine fault codes for easy troubleshooting.

2. Mature and reliable hydraulic top drive head. The main spindle adopts high load-bearing bearings for higher drilling accuracy. The main spindle seal adopts multiple sets of sealing design to ensure effective sealing. The air swivel adopts the company’s proprietary sealing technology, providing a long service life.

3. Roller sliding telescopic mast. The mast is made of forklift C-shaped steel, providing stable structure and high strength. The power head, inner mast sections, and outer mast sections all adopt roller sliding, resulting in minimal wear and high drilling accuracy.

4. Unique hydraulic matching technology. Multi-pump parallel distribution technology minimizes system heating and oil consumption. The integrated fine feed system has low pressure loss and allows precise adjustment of drilling pressure based on the weight of the drilling tools.

5. Safety-oriented design details. Multiple emergency stop buttons are installed to ensure the safety of the machine and personnel. The foldable foot pedal provides convenient operation.

6. Great potential for value appreciation. Optional drill rod box facilitates geothermal pump construction operations. Optional foam pump effectively reduces environmental pollution and improves slag discharge performance.



Product Display

160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m



160 Water Well Drilling Equipment400-500m
