Used Dump Truck

Used Dump Truck HOWO 20 Tons for sale

 Used Dump Truck Product Description

Used 20 Tons Tipper Truck Dump Truck

Truck ModelZZ3257N3847A
Truck BrandSINOTRUK -HOWO
Driving TypeLeft Hand Driving
Dimension(Lx W xH)(unloaded)(mm)8245x2550x3450
Cargo body size (L*W*H)5600x2300x1500    20m3
Cargo body thickness(mm)bottom:8mm, side:6mm
Lift type of CarriageVentral lifting
Approaching angle/Departure angle(°)19/23
Overhang(front/rear) (mm)1500/1870
Wheel base (mm)3625+1350
Max speed(km/h)75
Curb weight(kg)12600
Loading Weight(kg)20000
Fuel tanker capacity(L)300L with locking fuel cap
ClutchSingle-plate dry clutch Φ430mm
Engine Model
(Steyr technology, made in China)
ModelWD615.47
Horse Power371HP
EmissionEURO II
Fuel TypeDiesel
TransmissionModelHW19710,10 forwards and 2 reverse
Brake systemService brakeDual circuit compressed air brake
Parking brakespring energy, compressed air operating on rear wheels
Auxiliary brakeEngine exhaust brake
Steering systemModelZF hydraulic steering with power assistance,LHD
Ratio:22.2-26.2
Front axleHF9 , Steering with double T-cross section beam
Loading capacity:9000KG
Rear axleHC16, Pressed axle housing, central double reduction with differential locks between axles and wheels
Loading capacity: 16000kg
ColorOptional
Tire13R22.5 Steel tires
10+1 spare
Electrical systemOperating voltage24V,negative grounded
Starter24V,7.35KW
Alternator28V,1500W
Batteries2*12V.165Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.
CabHOWO76 cab, (single sleeper, with air-condition), all-steel forward control,70ºhydraulically tiltable to the front, 2- arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
Instrument PanelActive check central control with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging

Used 20 Tons Tipper Truck Dump Truck



Used 20 Tons Tipper Truck Dump Truck



Used 20 Tons Tipper Truck Dump Truck



Used 20 Tons Tipper Truck Dump Truck
