Basic Info.
| Vehicle type | 5500 | Condition | Used |
| Concrete production | 3.5 m³ per drum | Dimension | 7500×2300×4100 mm |
| Fuel tank capacity | 90 L | Wheelbase | 2300 mm |
| Gear position | 4 forward / 4 reverse | Curb weight | 8800 kg |
| Total hydraulic system capacity | 160 L | Tire model | 16/70 R22.5 dual tires |
| Engine oil capacity | 16 L | Maximum speed | 35 km/h |
| Reducer model | HJ80-43 | Max gradeability | 40° |
| Hydraulic pump model | CBG9 2050/2032 | Minimum turning radius | 5300 mm |
| Hydraulic motor model | MBTZ-250-B2BM | Ground clearance | 380 mm |
| Water tank capacity | 900 L | Engine model | Yuchai 4105 turbocharged engine |
| Drive system | Torque converter drive | Rated power | 85 kW |
| Geometric capacity of mixing drum | 5500 L | Transmission model | 280/315 split type |
| Drum rotation speed | 13-20 rpm (revolutions per minute) | Brand | HAITIAN |
| Country of Origin | China |
