Basic Info.
| Model | KM4000-25000MC | Condition | Used |
| Clamping Force | 40000 kN | Theoretical Injection Volume | 25000 cm³ |
| Screw Diameter | 150 mm/ 165 mm | Injection Weight (PS) | 25 kg |
| Injection Rate | Approx. 2000 – 2500 g/s | Plasticizing Capacity | Approx. 1500 – 2000 g/s (GPPS/HDPE) |
| Mold Opening Stroke | Approx. 2000 – 2200 mm | Minimum Mold Thickness | Approx. 800 – 900 mm |
| Injection Pressure | Approx. 1600 – 2000 bar (160 – 200 MPa) | Screw Speed | 0 – 80 rpm |
| Space Between Tie Bars | Approx. 2350 × 2300 mm | Ejector Stroke | Approx. 300 – 350 mm |
| Maximum Mold Thickness | Approx. 1600 – 1800 mm | Ejector Force | Approx. 300 – 350 kN |
| Servo Motor Power | Approx. 300 – 350 kW | Machine Overall Dimensions | Approx. 18000 × 3800 × 4800 mm |
| Heating Power | Approx. 70 – 80 kW | Machine Weight | Approx. 180 – 220 ton |
| Manufacture Date | 2019 | Brand | KraussMaffei |
| Origin | Germany |
