Basic Info.
| Model | 220T | Condition | Used |
| Engine Model | OM460LA.E3B/3 | Rated Total Lifting Capacity | 220 t |
| Max Rated Lifting Moment | 8712 kN·m | Complete Vehicle Kerb Mass | 54670 kg |
| Total Machine Mass | Approx. 72 t | Max. Allow Gross Mass | 54800 kg |
| Max Counterweight | 82 t | Max Rated Lifting Capacity / Working Radius | 220 t / 3m |
| Main Boom Length | 72 m | Boom Full Extend/Retract Time | Approx. 900 s |
| Jib Length | 36 m | Boom Full Raise/Lower Time | Approx. 80 s |
| Max Combined Boom Length | 120 m | Total Machine Length | 17200 mm |
| Total Machine Width | 3000 mm | Outrigger Span (Transverse × Longitudinal) | 9.5 m × 10.0 m |
| Total Machine Height | 4100 mm | Engine Rated Power | 480 kW / 1800 rpm |
| Overall Dimension(L×W×H) | 15720mm × 3000mm × 4000mm | Engine Rated Power / Rotational Speed | 360 kW / 1800 rpm |
| Max Driving Speed | Approx. 85 km/h | Engine Max Available Power / Rotational Speed | 360 kW / 1800 rpm |
| Max Climbing Gradient | 45% | Emission Standard | China VI |
| Min Ground Clearance | 290 mm | Max Slewing Speed | 1.5 r/min |
| Manufacture Date | 2020 | Brand | SANY |
| Origin | China |
